What Are Equipment and Asset Maps?
Equipment and Asset Maps allow organizations to pin equipment and assets directly onto building floor plans.
Instead of relying on text-based lists, teams can visually navigate the building and see where assets exist within rooms, corridors, mechanical spaces, and restricted areas.
Mapped assets may include:
- HVAC and mechanical equipment
- Electrical panels and distribution components
- Pumps, generators, and control systems
- IT and communications infrastructure
- Safety and life safety equipment
- Other critical facility assets
Each asset is tied to its physical location and supporting documentation.
Built for Real World Facility Operations
Facility work happens inside buildings, not inside spreadsheets.
Equipment and Asset Maps support:
- Commercial and corporate facilities
- Healthcare and hospital campuses
- Education and higher education
- Manufacturing and industrial facilities
- Government and public buildings
- Stadiums, arenas, and large venues
ARC Facilities scales across single buildings and multi-site environments.
Find Equipment Faster in the Field
When technicians cannot quickly locate equipment, work slows down.
With Equipment and Asset Maps, teams can:
- Navigate floor plans visually
- Tap mapped assets to view details
- Reduce time spent searching
- Arrive prepared with the right information
This shortens repair time and reduces downtime.
Add Location Context to Asset Information
Lists tell you what assets you have. Maps show you where they are.
Equipment and Asset Maps provide:
- Clear spatial context for assets
- Understanding of nearby systems and spaces
- Faster orientation for new staff and contractors
- Reduced mistakes caused by misidentification
Better context leads to better decisions.
Support Maintenance, Inspections, and Projects
Knowing where assets are located improves nearly every workflow.
Equipment and Asset Maps help teams:
- Prepare for maintenance before arriving onsite
- Support inspections and audits
- Coordinate work across trades
- Plan renovations and upgrades
- Reduce repeat visits
Location intelligence improves productivity across departments.
Mobile First for the Field
Facility teams work in mechanical rooms, rooftops, and back-of-house spaces.
ARC Facilities is mobile-first, allowing teams to:
- Access asset maps from phones or tablets
- Zoom and pan floor plans
- Tap assets to view documentation
- Share information quickly when authorized
No return trips to the office.
Reduce Risk and Reliance on Tribal Knowledge
When only a few people know where critical assets are located, organizations are vulnerable.
Equipment and Asset Maps help:
- Capture institutional knowledge
- Support faster onboarding
- Ensure consistent access across shifts
- Reduce errors
Knowledge becomes shared and reliable.
Accurate, Secure, and Always Current
Asset locations change over time. Information must keep up.
With ARC Facilities:
- Asset locations are stored securely in the cloud
- Updates can be made as assets move or change
- Authorized users always access current information
- Data is protected using enterprise-grade security standards
Teams can trust what they see.
Part of the Building Plans Solution
Equipment and Asset Maps works alongside other ARC Facilities Building Plans features, including:
- As-Builts List View
- As-Builts Map View
- Shutoff Mapping and Critical Systems
- Campus and Site Maps
- Other Maps and Building Resources
Together, these tools provide a complete visual understanding of building infrastructure.
We Do the Work for You
From collecting asset data to mapping equipment onto floor plans, ARC Facilities handles the setup. Your team receives organized, ready-to-use asset maps without added administrative burden.
Put Every Asset on the Map
Stop wasting time searching for equipment. Give your team instant, visual access to asset locations across every building.
Request a demo to see how Equipment and Asset Maps improves speed, accuracy, and operational efficiency.
